钕铁硼

产品介绍

	Unit	CGS Unit 物理单位				SI Unit 国际单位				Max Working Temp
NO.	Normal NdFeB	Remanence 剩磁	Coercive Force 娇顽力	Intrinsic Coercivity 内禀矫顽力	Max Energy Magnetic 最大磁能积	Remanence	Coercive Force	Intrinsic Coercivity	Max Energy Magnetic
		Br,KGS	HcB, KOe	HcJ, kOe	(BH)max,MGsOe	Br, T	HcB,kA/m	HcB,kA/m	(BH)max kJ/m3	Tw,℃
	Grade	min.- max.	min.	min.	min.- max.	min.- max.	min.	min.	min.- max.	Pc22
1	N35	11.7-12.2	≥11.0	≥12.0	33-36	1.17-1.22	≥876	≥955	263-287	≤80
2	N38	12.2-12.6	≥11.0	≥12.0	36-39	1.22-1.26	≥876	≥955	287-310	≤80
3	N40	12.5-12.9	≥11.0	≥12.0	38-41	1.25-1.29	≥876	≥955	302-326	≤80
4	N42	12.9-13.3	≥11.0	≥12.0	40-43	1.29-1.33	≥876	≥955	318-342	≤80
5	N45	13.3-13.7	≥11.0	≥12.0	43-46	1.33-1.37	≥876	≥955	342-366	≤80
6	N48	13.6-14.1	≥11.0	≥12.0	46-49	1.36-1.41	≥876	≥955	366-390	≤80
7	N50	14.0-14.4	≥11.0	≥11.0	48-51	1.40-1.44	≥876	≥955	382-406	≤80
8	N52	14.3-14.7	≥11.0	≥11.0	50-53	1.43-1.47	≥876	≥875	398-422	≤80
9	N54	14.7-15.0	≥10.4	≥11.0	52-55	1.47-1.50	≥835	≥875	414-438	≤70
10	N35M	11.7-12.2	≥11.2	≥14.0	33-36	1.17-1.22	≥892	≥1114	263-287	≤100
11	N38M	12.2-12.6	≥11.0	≥14.0	36-39	1.22-1.26	≥907	≥1114	287-310	≤100
12	N40M	12.5-12.9	≥11.0	≥14.0	38-41	1.25-1.29	≥907	≥1114	302-326	≤100
13	N42M	12.9-13.3	≥11.0	≥14.0	40-43	1.29-1.33	≥907	≥1114	318-342	≤100
14	N45M	13.3-13.7	≥11.0	≥14.0	43-46	1.33-1.37	≥907	≥1114	342-366	≤100
15	N48M	3.6-14.1	≥11.0	≥14.0	46-49	1.36-1.41	≥907	≥1114	366-390	≤100
16	N50M	14.0-14.4	≥11.0	≥14.0	48-51	1.40-1.44	≥907	≥1114	382-406	≤100
17	N52M	14.3-14.8	≥11.0	≥14.0	49-53	1.43-1.48	≥907	≥1114	390-422	≤100
18	N33H	11.4-11.7	≥10.3	≥17.0	31-34	1.14-1.18	≥820	≥1353	247-271	≤100
19	N35H	11.7-12.2	≥10.8	≥17.0	33-36	1.17-1.22	≥860	≥1353	263-287	≤120
20	N38H	12.2-12.6	≥11.0	≥17.0	36-39	1.22-1.26	≥907	≥1353	287-310	≤120
21	N40H	12.5-12.9	≥11.0	≥17.0	38-41	1.25-1.29	≥907	≥1353	302-326	≤120
22	N42H	12.9-13.3	≥11.4	≥17.0	40-43	1.29-1.33	≥907	≥1353	318-342	≤120
23	N45H	13.3-13.7	≥11.4	≥17.0	43-46	1.33-1.37	≥907	≥1353	342-366	≤120
24	N48H	13.6-14.1	≥11.4	≥17.0	46-49	1.36-1.41	≥907	≥1353	366-390	≤120
25	N50H	14.0-14.4	≥11.4	≥16.0	48-51	1.4-1.44	≥907	≥1273	382-406	≤110
26	N30SH	10.8-11.4	≥10.1	≥20.0	28-31	1.08-1.14	≥804	≥1592	223-247	≤150
27	N33SH	11.4-11.8	≥10.3	≥20.0	31-34	1.14-1.18	≥820	≥1592	247-271	≤150
28	N35SH	11.7-12.2	≥10.8	≥20.0	33-36	1.17-1.22	≥860	≥1592	263-287	≤150
29	N38SH	12.2-12.6	≥11.4	≥20.0	36-39	1.22-1.26	≥907	≥1592	287-310	≤150
30	N40SH	12.6-12.9	≥11.4	≥20.0	38-41	1.26-1.29	≥907	≥1592	302-326	≤150
31	N42SH	12.9-13.3	≥11.4	≥20.0	40-43	1.29-1.33	≥907	≥1592	318-342	≤150
32	N45SH	13.3-13.7	≥11.4	≥20.0	43-46	1.33-1.37	≥907	≥1592	342-366	≤150
33	N48SH	13.6-14.2	≥11.4	≥19.0	46-49	1.36-1.42	≥907	≥1512	366-390	≤140
34	N50SH	13.9-14.3	≥11.4	≥19.0	48-51	1.39-1.43	≥907	≥1512	382-406	≤140
35	N30UH	10.8-11.4	≥10.1	≥25.0	28-31	1.08-1.14	≥804	≥1990	223-247	≤180
36	N33UH	11.4-11.8	≥10.3	≥25.0	31-34	1.14-1.18	≥820	≥1990	247-271	≤180
37	N35UH	11.7-12.2	≥10.8	≥25.0	33-36	1.17-1.22	≥860	≥1990	263-287	≤180
38	N38UH	12.2-12.6	≥11.4	≥25.0	36-39	1.22-1.26	≥907	≥1990	287-310	≤180
39	N40UH	12.5-12.9	≥11.4	≥25.0	38-41	1.25-1.29	≥907	≥1990	302-326	≤180
40	N42UH	12.8-13.2	≥11.4	≥25.0	40-43	1.28-1.32	≥907	≥1990	318-342	≤180
41	N45UH	13.2-13.6	≥11.4	≥25.0	43-46	1.32-1.36	≥907	≥1990	342-366	≤180
42	N28EH	10.4-10.8	≥9.8	≥30.0	26-29	1.04-1.08	≥780	≥2388	207-231	≤200
43	N30EH	10.8-11.4	≥10.1	≥30.0	28-31	1.08-1.14	≥804	≥2388	223-247	≤200
44	N33EH	11.4-11.8	≥10.3	≥30.0	31-34	1.14-1.18	≥820	≥2388	247-271	≤200
45	N35EH	11.7-12.2	≥10.8	≥30.0	33-36	1.17-1.22	≥860	≥2388	263-287	≤200
46	N38EH	12.2-12.6	≥11.5	≥30.0	36-39	1.22-1.26	≥915	≥2388	287-310	≤200
47	N40EH	12.5-12.9	≥11.5	≥28.0	38-41	1.25-1.29	≥915	≥2229	302-326	≤190
48	N42EH	12.8-13.2	≥11.4	≥28.0	40-43	1.28-1.32	≥907	≥2229	318-342	≤190
49	N28AH	10.4-11.0	≥9.8	≥34.0	26-29	1.04-1.10	≥780	≥2706	207-231	≤230
50	N30AH	10.8-11.4	≥9.8	≥34.0	28-31	1.08-1.14	≥780	≥2706	223-247	≤230
51	N33AH	11.4-11.8	≥9.8	≥34.0	31-34	1.14-1.18	≥780	≥2706	247-271	≤230
52	N35AH	11.7-12.2	≥9.8	≥34.0	33-36	1.17-1.22	≥780	≥2706	263-287	≤230
53	N30SH-T	10.8-11.4	≥10.1	≥23.0	28-30	1.08-1.14	≥804	≥1831	223-239	≤165
54	N33SH-T	11.4-11.8	≥10.3	≥23.0	30-33	1.14-1.18	≥820	≥1831	239-263	≤165
55	N35SH-T	11.7-12.2	≥10.8	≥23.0	33-36	1.17-1.22	≥860	≥1831	263-287	≤165
56	N38SH-T	12.2-12.6	≥11.4	≥23.0	36-38	1.22-1.26	≥907	≥1831	287-303	≤165
57	N40SH-T	12.5-12.9	≥11.4	≥23.0	38-40	1.25-1.29	≥907	≥1831	303-318	≤165
58	N42SH-T	12.9-13.3	≥11.4	≥23.0	40-42	1.29-1.33	≥907	≥1831	318-334	≤165
59	N45SH-T	13.3-13.7	≥11.4	≥23.0	42-45	1.33-1.37	≥907	≥1831	334-358	≤165
60	N30UH-T	10.8-11.4	≥10.1	≥27.0	28-30	1.08-1.14	≥804	≥2149	223-239	≤190
61	N33UH-T	11.4-11.7	≥10.3	≥27.0	30-33	1.14-1.17	≥820	≥2149	239-263	≤190
62	N35UH-T	11.7-12.2	≥10.8	≥27.0	33-36	1.17-1.22	≥860	≥2149	263-287	≤190
63	N38UH-T	12.2-12.6	≥11.4	≥27.0	36-38	1.22-1.26	≥907	≥2149	287-303	≤190
64	N40UH-T	12.5-12.9	≥11.4	≥27.0	38-40	1.25-1.29	≥907	≥2149	303-318	≤190
65	N42UH-T	12.8-13.2	≥11.4	≥27.0	40-42	1.28-1.32	≥907	≥2149	318-334	≤190
